Taking our 15 years of carbon fiber experience we set out to test our skills at developing a truly breathtaking bike that balances comfort, stability, direct power transfer and the ability to radically reduce drag. The ELYSIUM Aero is the fastest bike we have ever created.
Our engineered front cowling shields the wind and aids in a really stiff fork-head tube structure. The ELYSIUM’s dynamic structure handles varying wind angles combined with the new direct mount brake callipers which hide the front and rear brakes completely from frontal air. A flattened and triangulated top tube manages side wind and an integrated seat clamp and tucked rear wheel creates minimal drag by cleaning up dirty trailing air.All of this helps the ELYSIUM Aero slip through the air allowing you to beat your personal bests.
A wide range adjustable post makes it suitable for Triathlon and Competition Time Trials without the need to change equipment - enhanced ergonomics and geometry allow its pilot to be in the most aero position possible.
Ride with low flying aircraft.
Proudly Designed and Engineered in Gavà, Spain.
BUILD KITS
| RR - RED22 | R - FORCE22 | |
|---|---|---|
| FORK | MSC Tapered Aero Shield | MSC Tapered Aero Shield |
| REAR SHOCK | No | No |
| HEADSET | MSC ULTRALIGHT | MSC ULTRALIGHT |
| FRONT DER. | RED22 | FORCE22 |
| REAR DER. | RED22 | FORCE22 |
| SHIFTERS | RED22 | FORCE22 |
| CRANKS | RED22 BB30 | FORCE22 |
| BRAKES | RED AeroLink | FORCE |
| TYRES | MAXXIS RADIALE 23c | MAXXIS RADIABLE 23c |
| WHEELS | ENVE 6.7 | MSC Carbon 60mm Clincher |
| HANDLEBAR | ENVE SES AERO 40cm | Zipp SC SL70 42cm |
| STEM | ENVE 318 120mm | ZIPP SC SL 120mm |
| SADDLE | SELLE SAN MARCO Aspide FX | SELLE SAN MARCO Aspide FX |
| POST | ENVE 31.8 Offset | MSC Ultralight 31.8mm |
FRAME SPECS
| TRAVEL | 0mm |
| WEIGHT | 780g |
| SIZES | XS, SML, MED, LRG |
| REAR SHOCK | No |
| AXLE COMPATIBILITY | 135X12 / 142 X 12 |
| FRONT DER. | BRAZE ON |
| SEATPOST | 31.6MM |
| BUILDS | RR / R / CUSTOM |
| ELYSIUM RR | $8,495.00 |
| ELYSIUM R | $6,995.00 |
| ELYSIUM FRAMESET | $2,795.00 |
| ELYSIUM FRAME + CUSTOM | Contact Us |
GEOMETRY
| SMALL | MEDIUM | LARGE | |
|---|---|---|---|
| 571.80 | 591.10mm | 609.25mm | |
| A | 609.20mm | 591.10mm | 571.80mm |
| A' | 588mm | 610mm | 629 |
| B | 426mm | 445mm | 483mm |
| C | 449mm | 449mm | 449mm |
| D | 699.70mm | 722.80mm | 741.50mm |
| E | 1137mm | 1160mm | 1178mm |
| F | 67.5º | 67.5º | 67.5º |
| G | 72.50º | 72.50º | 72.50º |
| H | 120mm | 125mm | 130mm |
| H | 16mm | 16mm | 16mm |
